Beyond 5GigE Performance

Genie Nano 5GigE

Introducing the Genie Nano-5GigE, a GigE Vision CMOS area scan camera that redefines high performance. Genie Nano starts with industry leading image CMOS sensors from 3.2 to 45 megapixel and adds proprietary camera technology for breakthrough speed, a robust build quality for wide operating temperature, and an unmatched feature set — all at an incredible price. Teledyne DALSA’s proprietary TurboDrive™ technology allows Genie Nano to deliver its full image quality at faster frame rates — often 150% or higher.

Watch Video


The new standard for speed

Engineered for imaging applications that require high-speed data transfer, the all new Genie Nano 5GigE is an easy replacement for gigabit ethernet cameras built into current vision systems that rely on the existing GigE Vision interface standard. The new Genie Nano 5GigE models feature the brand new 5Gbps (5GBASE-T) link speed.

When combined with Turbodrive, you get the same throughput as 10GigE but lower cost of ownership.


5 GigE

595 MB/s
Without TurboDrive


5 GigE

985 MB/s
With TurboDrive





Flexible and powerful

Like all Genie Nano cameras, the new Genie Nano 5GigE models are offered in a compact form and available in multiple resolutions ranging from 3.2MP to 45MP, with fast frame rates to fill the entire 5GigE bandwith (and more, with Turbodrive). System designers for industrial automation, electronics manufacturing, packaging, semiconductor inspection, and general machine vision inspection can expect a smooth integration path to extend the life of an existing system with little difficulty.



Family Specifications

Camera Type Area Scan
Sensor Technology CMOS
Supported Interfaces GigE Vision
Spectrum Capability Visible (400-700 nm), Near Infrared (700-1000 nm)
Features TurboDrive, T2IR
Options Color models available with IR cut-off filter @650 nm


Model Finder

Megapixels

Show All

Horizontal Resolution

Show All

Frame Rate

Show All

Spectrum

Show All

Sensor

Show All

Results:

Reset Filters
Showing 14 results
Product MP FPS Pixel Size (μm) Interface Spectrum Price Compare Options
Genie Nano 5G C2050 Color
G5-GC30-C2050
3.2 187 3.45 5 GigE Color In Production Request Info Genie Nano 5GigE
Genie Nano 5G C2450 Color
G5-GC30-C2450
5.1 121 3.45 5 GigE Color In Production Request Info Genie Nano 5GigE
Genie Nano 5G C4040 Color
G5-GC30-C4040
12.3 49 3.45 5 GigE Color In Production Request Info Genie Nano 5GigE
Genie Nano 5G C4060 Color
G5-GC30-C4060
8.9 68 3.45 5 GigE Color In Production Request Info Genie Nano 5GigE
Genie Nano 5G C4500 Color
G5-GC31-C4505
20.2 28.9 3.2 5 GigE Color Preproduction Request Info Genie Nano 5GigE
Genie Nano 5G C5420 Color
G5-GC31-C5425
29.3 15 3.2 5 GigE Color Preproduction Request Info Genie Nano 5GigE
Genie Nano 5G C8100 Color
G5-GC31-C8105
44 14 3.2 5 GigE Color In Production Request Info Genie Nano 5GigE
Genie Nano 5G M2050 Mono
G5-GM30-M2050
3.2 187 3.45 5 GigE Mono In Production Request Info Genie Nano 5GigE
Genie Nano 5G M2450 Mono
G5-GM30-M2450
5.1 121 3.45 5 GigE Mono In Production Request Info Genie Nano 5GigE
Genie Nano 5G M4040 Mono
G5-GM30-M4040
12.3 49 3.45 5 GigE Mono In Production Request Info Genie Nano 5GigE
Genie Nano 5G M4060 Mono
G5-GM30-M4060
8.9 68 3.45 5 GigE Mono In Production Request Info Genie Nano 5GigE
Genie Nano 5G M4500 Mono
G5-GM31-M4505
20.2 28.9 3.2 5 GigE Mono Preproduction Request Info Genie Nano 5GigE
Genie Nano 5G M5420 Mono
G5-GM31-M5425
29.3 15 3.2 5 GigE Mono Preproduction Request Info Genie Nano 5GigE
Genie Nano 5G M8100 Mono
G5-GM31-M8105
44.4 14 3.2 5 GigE Mono In Production Request Info Genie Nano 5GigE

Media gallery

Resources & Support

News

Teledyne DALSA’s Genie Nano-5G camera now in full production

Read the Story

News

Faster GigE vision interface cameras engineered for high-resolution image capture

Read the Story

Application Overview

Battery Inspection

Read the Story

Technology Primer

CCD vs CMOS

Read the Story

Warranty & RMA

Teledyne DALSA Warranty Information

Read the Story

Below are assets shared by all models of this product family.

For model-specific assets, select an option in the Model Finder above.

You must be logged in to download software or firmware. Please sign in or create an account here.

Cognex Adapter for Teledyne DALSA Frame Grabbers & GigE Vision Cameras

Driver

Last Updated: March 03, 2020

Version: 1.20

Download

Genie Nano 5 GigE Firmware

Firmware Download

Last Updated: November 25, 2019

Version: 1.00

Download

Below are assets shared by all models of this product family.

For model-specific assets, select an option in the Model Finder above.

App Note G3-AN0010 - Run Length Encoding Algorithms for Genie Nano GigE

Application Note

Download

G3-AN0004 - Genie Nano: Comparing TurboDrive v2.0 with TurboDrive v1.0 algorithm

Application Note

Download

G3-AN0008 - Genie Nano - How to Multicast with Sapera LT

Application Note

Download

Genie Nano 5GigE Family Datasheet

Datasheet

Download

Genie Nano 5GigE Material Composition Product Declaration

Certification

Download

Genie Nano 5GigE Series User Manual

User Manual

Download

Genie Nano Family Datasheet

Datasheet

Download

Genie Nano Material Composition Product Declaration

Certification

Download

ISR and Defense Mission Components Brochure

Brochure

Download

Machine Vision Brochure

Brochure

Download
