Lince11M

Model: EV2S11MB-CLV0500-T
product image

Lince 11M has been specifically designed as a high-speed CMOS image sensor that also allows customers to decrease the cost of ownership. The digital circuits of the sensor output images at 715 fps in 4K resolution, or 1400 fps when windowing in full HD resolution. To facilitate access to affordable optics, Lince11M is compatible with APS-C format in 4K resolution.

Key Specs

Resolution
Frame Rate
Optical Format
11.1M
609 fps
31 mm
In Production

Lince Overview

Teledyne e2v's Lince family of CMOS image sensors are designed for high-speed imaging, providing unrivaled frame rates in native resolutions from 1.3M to 11M, that can be further increased with various on-chip features. As obtaining good image quality at high speed can be particularly challenging, Lince sensors feature large global shutter pixels providing high sensitivity and high SNR to benefit from high contrast in a very short time.



Ideal for Freezing Motion

In motion capture, Lince11M enables users to detect markers at sub-mm accuracy from longer distances, and reduce the number of cameras necessary to prevent occlusion and minimize Field of View reduction, in order to track complex motion.



Upgrading High-Speed Inspection Equipment

Lince11M offers a path forward for customers that traditionally use monochrome images for defect classification due to a lack of speed. This sensor combines high-speed and large resolution (outputting 7 Gpix/s), so that customers can upgrade their LED lighting and detect smaller defects. They can also increase the contrast of their images by strobing several light sources for multispectral imaging (multiple colors) or multifield imaging (multiple angles).




Specifications

Technology
2D
Resolution
11.1M
Resolution - Horizontal Pixels
4480
Resolution - Vertical Pixels
2496
Optical Format
31 mm
Lens Mount Compatible
APS, F-mount, TFL-mount, 35mm, M42
Shutter type
Global
Interface
LVDS
Maximum Package Size - Horizontal
50
Maximum Package Size - Vertical
46
Pixel Size - Horizontal
6
Pixel Size - Vertical
6
Chroma (Standard)
Mono
Spectrum
Visible
Frame/Line Rate
609 fps
NIR Enhanced
No
Image Sensor CRA
N/A
Sensor Family
Lince

Resources & Support

Lince11M Flyer

Standard CMOS Image Sensor Guide

Brochure
