Introducing T2IR



Seeing is Believing

If your machine vision system shows you something, you'd like to be able to trust it. But the reality is that a lot can go wrong in a complex imaging system. If your system is a "black box", how can you tell if your data is complete and correct—is it "the truth, the whole truth, and nothing but the truth"? If something does go wrong, can you tell what where, and more importantly why?

Teledyne's Trigger-to-Image Reliability framework can give you the answers. T2IR is a combination of hardware and software features that work together at a system level to help you improve the reliability of your inspection system. It controls and monitors the entire process from trigger through image capture and transfer to host memory and helps protect you from data loss.


T2IR Benefits

  • Makes system more predictable
  • Prevents many errors before they happen
  • Lets your system manage exceptions in controlled manner
  • Provides system debugging and tracing
  • Reduces downtime
  • Improves application response time
  • Increases robustness

Situations Where T2IR Helps

  • Too many objects fall in front of the camera (over triggering)
  • Need to troubleshoot a device
  • Need to verify critical imaging events such as lost frames, lines, triggers etc.
  • Need to build verification into applications as part of runtime operation
  • Want applications to be portable across devices and platforms
  • Want to tag images for traceability
  • In overload conditions, want to skip some inspections but keep track of what was skipped



Download T2IR Primer

Get the in-depth technical details on how T2IR works.

Download the primer now


Frequently Asked Questions

Get answers to the most common T2IR questions.

Read the FAQ




Supported Products

Compatible Product Families Product Type Product Technology
Genie Nano Cameras Area Scan
Forge 5GigE Cameras Area Scan
Oryx 10GigE Cameras Area Scan
Blackfly S GigE Cameras Area Scan
Blackfly S USB3 Cameras Area Scan
Blackfly S Board Level Cameras Area Scan
Linea Cameras Line Scan
Piranha4 Cameras Line Scan
Piranha XL Cameras CMOS TDI Line Scan
Xtium Family Frame Grabbers CameraLink
Xcelera Family Frame Grabbers CameraLink
Sapera LT SDK (Windows & Linux) Software Application Development
